Parking sensor set for camera and LCD display, 4 silver sensors 22 mm AMIO-02990

The sensor kit with the option to connect a rear view camera is a basic solution for installing a parking system with video display. The kit can be supplemented with one of our LCD screens (P/N: 01020 or P/N: 02484) and a selected camera from a wide range.

The system can also be connected to a car radio that supports PAL/NTSC video signal.

Parking assistant is a reliable auxiliary device that facilitates parking and reversing. A universal and practical solution for drivers who value safety and comfort. The system works automatically and does not require complex control. Ultrasonic sensors accurately detect obstacles, and the driver is warned about them with an audio signal and visual information on the screen. The intensity of the audio signals changes depending on the distance to the obstacle.

Technical specification:

• Power supply: 12V DC
• Power consumption: < 4 W
• Operating frequency: 40 kHz
• Operating temperature: -30 °C to +55 °C
• Obstacle detection distance: 0.3-2.5 m
• Measurement error: ±5 cm
• Sensor cable length: 2.2 m
• Display cable length: 5 m

The set includes:

• TFT control unit with connection for display and camera
• Parking sensors
• Connecting wires
• Installation drill
• Instructions for use

Sensors can be installed at the front or rear of the vehicle, choosing the desired arrangement, thus increasing safety when maneuvering.

The rear sensors are activated automatically when reverse gear is engaged, and the front sensors are activated when the brake pedal is pressed. The control unit is calibrated at the factory.

The front sensors are activated when braking - the system operates for 15 seconds after pressing and releasing the brake pedal. It also automatically activates if an obstacle is detected up to 80 cm from the car.

Obstacle detection is signaled by:

• at the displayed distance,
• graphical indication on the screen,
• with an audible signal through the integrated speaker.

The kit uses high-quality sensors with a flat mounting edge, ensuring aesthetic and precise installation into the bumper.

The sensors are completely waterproof and work reliably in rain, snow or fog.

If necessary, the sensors can be painted with 1-2 coats of paint (done independently).

A universal solution suitable for most passenger cars. If necessary, cable extensions can be used for trucks or commercial vehicles if the standard length of the kit cables is not sufficient.
